1： Main structural features of industrial dryer
1: The industrial dryer has the advantages of high efficiency, fast heating up, reasonable structure, low noise and easy operation. Steam heating and electric heating are available
2: The electric heating tube of industrial dryer is made of stainless steel, which has the advantages of fast heating and high heating efficiency.
3: The inner liner of industrial dryer is made of stainless steel plate.
4: Industrial dryer with computer controller, stable performance, accurate temperature control.
5: Industrial dryer is mainly used in garment factories, washing factories, hotels, hotels, hospitals, industrial and mining enterprises, etc.
2、 Main technical specifications of dryer
| (mm) | (kw) | Motor power exhaust fan(KW) | electric heating power (kw) |
| MPa steam pressure | note | |
SWA801-10 | 700*1100*1340 | φ640*560 | 0.55 | 0.55 | 7.2 | 46 | 0.4-0.6 |
|
900*1200*1500 | φ760*560 | 0.75 | 0.75 | 10.8 | 35 | 0.4-0.6 | ||
SWA801-30 | 1100*1450*1900 | φ950*860 | 1.1 | 1.1 | 18 | 32 | 0.4-0.6 | |
SWA801-50 | 1320*1700*2200 | φ1160*1000 | 1.5 | 1.5 | 21 | 32 | 0.4-0.6 | |
SWA801-100 | 1500*1800*2390 | φ1320*1100 | 2.2 | 2.2 | 39 | 30 | 0.4-0.6 | |
SWA801-100(雙) | 1620*1800*2410 | φ1500*1000 | 2.2 | 2*1.5 | - | 30 | 0.4-0.6 |
|
SWA801-120 | 1620*1850*2410 | φ1500*1080 | 2.2 | 2*1.5 | - | 28 | 0.4-0.6 | |
SWA801-120(新) | 1650*1900*2470 | φ1470*1180 | 2.2 | 2*2.2 | - | 26 | 0.4-0.6 |
|
SWA801-120（臺(tái)） | 2100*1900*2380 | φ1470*1180 | 2.2 | 2*2.2 | - | 26 | 0.4-0.6 | |
SWA801-150 | 1740*1900*2550 | φ1600*1160 | 3 | 2*2.2 | - | 27 | 0.4-0.6 | |
SWA801-180（港） | 1900*1850*2650 | φ1800*1100 | 4 | 2*2.2 | - | 24 | 0.4-0.6 | |
SWA801-30T | 1100*1450*1900 | φ950*800 | 1.1 | 1.1 | - | 32 | - |
|
SWA801-50T | 1320*1700*2200 | φ1160*1000 | 1.5 | 1.5 | - | 32 | - | |
SWA801-100T | 1485*1800*2360 | φ1320*1100 | 2.2 | 2.2 | - | 30 | - |
|
SWA801-120T | 1620*1850*2400 | φ1500*1080 | 2.2 | 2.2 | - | 28 | - | |
SWA801-150T | 1740*1900*2600 | φ1600*1160 | 3 | 2.2 | - | 27 | - |
3、 Product introduction
The drying machine can be automatically controlled according to different drying time and drying time. The inner cylinder of the dryer is made of bright stainless steel plate with excellent heat resistance. The inner wall is smooth and the wear of clothes is reduced. The dryer has high efficiency radiator and reasonable air duct to make hot air contact with clothes directly, which greatly improves drying efficiency and saves energy. The dryer has a large diameter feed inlet, which is convenient for clothes in and out. Large area of plush collection net, not easy to cause fluff blockage, protect the smooth air duct, thus greatly improving the drying efficiency. The dryer can be selected from steam heating, electric heating and natural gas.
